Quick Details

  • Place of Origin: Guangdong, China (Mainland)
  • Brand Name: TOPLED
  • Model Number: p10
  • Usage: Outdoor
  • Tube Chip Color: Full Color
  • Display Function: Video
  • Pixels: 10mm
  • Screen Dimension: Customize
  • Piexl Density: 10000Piexl/sqm.
  • Piexl composition: 1R+1G+1B
  • Module Resolution: 16PiexlX16Piexl
  • Cabinet Resolution: 96PiexlX96Piexl
  • Module Dimension: 160mmX160mm
  • Cabinet Dimension: 960mmX960mm
  • Brightness: >=6000cd/sqm
  • Optimal Viewing Distance: >10m
  • Max.Power consumption: 1000w/sqm
  • Inputting Voltage: 220V/110V

Packaging & Delivery

Packaging Details Wooden case,Honeycomb case, flight cases for your option.
Delivery Time 10-15working days
Product Description



 p10 outdoor led display module







 I.  p10 outdoor led display module



1.advanced digital view frenquency treatment technology

2.scan by distributed & design with modularization

3.static drive by constant-current,brighteness adjust willingly

4.super high brighteness & soled color pixel

5.vivid menu,no dithering and double image,stop distortion

6.web control or long-distance control





  II.  P10  electronic commercial display Module & Cabinet























 P10  electronic commercial display   specification



Parameter

Value

Brightness (calibrating value)

≥9000nits

View Angle (min, 50% brightness)

H≥120°  V≥50°

Viewing distance:

15~200m

Brightness Control

100 levels

Grey Scale

4096

Refresh Rate (PAL/NTSC) minimum

≥400Hz

Frame Rate

≥60Hz

Drive Type

Constant current drive

Scan Type

Static

Input Voltage

AC 220/110V±15%

Color Temperature

6500 deg. k

Defects Rate

≤0.00001

MTBF

Greater than 10,000 hs

Life Span( 50% Brightness)

Greater than 100,000 hs

Module Brightness Uniformity

≤4%

Ingress Protection

Front IP65  Rear IP43

Neat degree:

Each pixel to the next one ≤0.5mm;

Interstice between every two Neighboring module <1mm

Earth Leakage Current

<1.5mA

Operating Temperature

-30°C ~ +60°C

Storage Temperature

-40°C ~ +85°C

Operating Humidity Range

operating   10~96%

Control Mode

Synchronized or in phrase

Communication distance:

Cat.5 communication cable(without relay) not over 130m;

Multi-mode optical fiber: 500m;

Single-mode optical fiber: 10km-20km

Display Input Format (with Video Processor)

VGA, DVI, RGBHV, PbPr(HDTV), Composite, S-Video, TV

OS

WIN2000/XP/7

Controller

Data sending card+ Data Receiving card+ Video card



 ATTENTION



In order to offer you a suitable solution ,Please state general info about your project.
P6 Full Color Outdoor LED Advertising Display Screen Panel



1,Pixel pitch or view distance you need.
2,Dimension
3,Location of installation.( eg, on poles, on wall of building, ect)
4,Purpose.( what are you going to do with the LED Screen)

 Packing

Packaging & Shipping

Shipping

Delivery in 15 working days after got deposit.



Company Information



    ShenZhen TOPLED Optotech Co.,Ltd is a professional led manufacturer established in May 2006, which is a high-tech company specializing in LED researching, manufacturing, marketing and engineering service to provide customers with high-quality services.

    TOPLED’S business covers indoor and outdoor led display, led curtain, LED components, LED multimedia advertising screen, stadium display, highway and transportation changeable message sign, rental display, indoor and outdoor led lighting etc.

Certifications and Honors

TOPLED's Successful Cases

Our Services




FAQ



Why so many clients choose TOPLED?



Our led display has applied many countries in the world. Many countries have our projects.



TOPLED's led display unique advantage



-------service



>Our engineer will be on your service. We can give you technology support at any time.

We will be tracking your orders, from the pre-sale to the after-sale and also serve you in this process.



--------price



Our price is based on the quantity, We have the basic price for one square meter. For each additional 5 square meter will have a discount when beyond 10 square meter. What is more, free power and fan will send to youThe cabinet will be free.



--------Quality



Quality is our reputation, we have eight steps for our quality inspection, From material to the finished goods. Quality is what we pursuit.



Choose TOPLED, you choose the cost-effective , high quality and good service.
